ProSecure Unified Threat Management (UTM) Appliance Reference Manual
7-52 Virtual Private Networking Using IPsec Connections
v1.0, January 2010
4. Click on the disk icon to save the configuration, or select File > Save from the Security Policy
Editor menu.
Use Select the Use checkbox. Then, from the pull-down menu, select Secure
Gateway Tunnel.
ID Type
Left pull-down menu From the left pull-down menu, select Domain Name.
Then, below, enter the local FQDN that you specified
in the UTM’s Mode Config IKE policy. In this example,
we are using utm25_local.com.
Right pull-down menu From the right pull-down menu, select Gateway IP
Address. Then, below, enter the IP address of the
WAN interface that you selected on the UTM’s VPN
Wizard screen (see Figure 7-9 on page 7-10). In this
example, the WAN IP address is 192.168.50.61.
Note: You can find the WAN IP address on the
Connection Status screen for the selected WAN port.
For more information, see “Viewing the WAN Ports
Status” on page 11-27.
Table 7-17. Security Policy Editor: Remote Party, Mode Config Settings (continued)
Setting Description (or Subfield and Description)
