ProSecure Unified Threat Management (UTM) Appliance Reference Manual
Using the Setup Wizard to Provision the UTM in Your Network 2-3
v1.0, January 2010
3. In the User field, type admin. Use lower case letters.
4. In the Password field, type password. Here too, use lower case letters.
Figure 2-1
Note: The first time that you remotely connect to the UTM with a browser via an SSL
connection, you might get a warning message regarding the SSL certificate.
You can follow to directions of your browser to accept the SSL certificate, or
you can import the UTM’s root certificate by clicking the hyperlink at the he
bottom of the NETGEAR Configuration Manager Login screen.
Note: The UTM user name and password are not the same as any user name or
password you might use to log in to your Internet connection.
